Specifications *

• Model: MINI MADIX 110
• Engine: 110cc, 4 Stroke, Air-cooled
• Remote Starter and Kill Switch
• Transmission: Automatic Chain Transmission + Reverse
• Cylinder: Single Cylinder
• Carburetor: PZ19
• Air Filter: Dry Air Filter Net
• Spark Plug: A7TC
• Max Speed: 45 km/h
• Start: Electric
• Final Drive: Axle Shaft
• Battery: 12V/5AH
• Engine Oil: 0.7L
• Suspension Front: Double Swing Arm, Oil dampers
• Suspension Rear: Single Swing Arm, Oil dampers
• Shock Absorber Front: Double
• Shock Absorber Rear: Single
• Brakes Front: Drum Brake
• Brakes Rear: Disc Brake
• Brake Distance: 7m/30km/h
• Tires Front: 145/70-6
• Tires Rear: 145/70-6
• Seat Height: 25"
• Seat to Boot Pegs: 14.5"

• Wheel Base: 34"
• Back of seat to handlebars: 23"
• Handle bars to ground: 34"
• Handle Bar to Handle Bar: 27"
• Dimensions Assembled: 50" x 33" x 34"
• Ground Weight: 85 kg
• Turning Radius: 2000mm
• Tank Capacity: 1.5L

  * - PRODUCT SPECIFICATIONS AND DATA ARE SUBJECT TO CHANGE WITHOUT NOTICE TO IMPROVE RELIABILITY, FUNCTION OR DESIGN OR OTHERWISE
